    accuracy 380V Voltage Nc Sheet Cut Off Machine for Corrugated Cardboard Manufacturing

    Ask Lasest Price
    Brand Name : LIHENG
    Supply Ability : 1000 Set/Sets per Year
    Price : $9,286.00 - $21,420.00/sets
    • Product Details
    • Company Profile

    accuracy 380V Voltage Nc Sheet Cut Off Machine for Corrugated Cardboard Manufacturing

    Product Description
    accuracy 380V Voltage Nc Sheet Cut Off Machine for Corrugated Cardboard Manufacturing
    accuracy 380V Voltage Nc Sheet Cut Off Machine for Corrugated Cardboard Manufacturing
    Product Details

    NC cut off :

    accuracy 380V Voltage Nc Sheet Cut Off Machine for Corrugated Cardboard Manufacturing

    Function :

    Effective width :1400mm
    Design speed : 80m/min-120min
    Mechanical configuration : slitter and NC straight knife
    Min cutting length : 300mm
    Max cutting length : 9999mm
    Cutting accuracy :±1mm(uniform speed)±1.5mm (non-uniform speed )
    Five group ȼ 160 round knife Memory of 200 orders, man-machine interface, the screen displays information available, easy for machine operator modify or cancel order at Any time.
    Adopt Germany KEB servo system and high performance synchronous Servo motor.
    Helical knives structure with HSS knife edge, serration type knife and scissor cutting with less shear force, to keep the knives long life.
    Host base and machine frame adopt grey cast iron, to keep machine Strong and stable.
    Adopt 3 section up stacker , the paperboard automatic side delivery after reach setting quantity. Max.stacking length 1.3meters.
    This machine suitable for offset printing business.
    Double layer NC cut off :
    accuracy 380V Voltage Nc Sheet Cut Off Machine for Corrugated Cardboard Manufacturing
    accuracy 380V Voltage Nc Sheet Cut Off Machine for Corrugated Cardboard Manufacturing

    Function :

    Effective width : 2200MM
    Design speed : 120min
    Mechanical configuration : slitter and NC Heclial knife
    Min cutting length : 300mm
    Max cutting length : 9999mm
    Cutting accuracy :±1mm(uniform speed)±1.5mm (non-uniform speed ).
    Five group ȼ 160 round knife .
    Memory of 200 orders, man-machine interface, the screen displays information available, easy for machine operator
    modify or cancel order at Any time .
    Adopt Germany KEB servo system and high-performance synchronous Servo motor.
    Helical knives structure with HSS knife edge, serration type knife and scissor cutting with less shear force, to keep the knives long life.
    Host base and machine frame adopt grey cast iron, to keep machine Strong and stable.
    Adopt 3 section up stacker , the paperboard automatic side delivery after reach setting quantity. Max.stacking length 1.3meters.
    This machine suitable for offset printing business.
    Specification
    Max. working width
    1400mm
    Min. working width
    900mm
    Max. paper mill diameter
    1500mm
    Max working pneumatic pressure:
    0.6-0.9Mpa
    Power requirements:
    380V, 50Hz
    Length of track for carry paper mill
    6000mm
    Product packaging
    accuracy 380V Voltage Nc Sheet Cut Off Machine for Corrugated Cardboard Manufacturing
    Recommend Products
    accuracy 380V Voltage Nc Sheet Cut Off Machine for Corrugated Cardboard Manufacturing
    Company Profile
    accuracy 380V Voltage Nc Sheet Cut Off Machine for Corrugated Cardboard Manufacturing
    Our Advantages
    accuracy 380V Voltage Nc Sheet Cut Off Machine for Corrugated Cardboard Manufacturing
    Certifications
    accuracy 380V Voltage Nc Sheet Cut Off Machine for Corrugated Cardboard Manufacturing
    Exhibition
    accuracy 380V Voltage Nc Sheet Cut Off Machine for Corrugated Cardboard Manufacturing
    accuracy 380V Voltage Nc Sheet Cut Off Machine for Corrugated Cardboard Manufacturing
    1.Q:Are you a manufacturer?
    A: Yes ,we make all the machines related to corrugated cardboard and carton box.

    2. Q:Do you have export licence ?
    A: Yes ,we have export licence and we can export by ourselves .

    3. Q:Where are you located ?
    A: We are located in dongguang city ,cangzhou city ,hebei pronvice , China ,

    4. Q:How to travel to your city ?
    A: Our nearest airport are beijing international airport , and jinan airport , our nearest high speed train station is cangzhou
    west station.It only takes two and a half hours to my city by car ,and only 1 hour from beijing south station to cangzhou west station by high speed train .

    5. Q:About quality control and delivery?
    A: Inhouse inspection and third party inspection. Our delivery time is on time.

    6. Q:The process of buying machines from our company ?
    A: Describe your requirements --- quote the price - accpet the price - make the contract -- prepare the machine - check the
    machine-ship the machine

    7. Q: Do you have any working machine for us to visit?
    A: Yes,We have running machine near our factory also in our city, so we can arrange the visiting.

    8. Q: What is the warranty time of the machine?
    A: Our machines have One YEAR WARRANTY. Engineers are available for oversea service.

    9. Q:Is it safe on the payment for me as we are the first cooperation?
    A: We can do the trade assurance on Alibaba, which will guarantee your products receiving. We also accept other safe payment ways you want.
